Product Summary

The AT-41511 is a general purpose NPN bipolar transistor that offers excellent high frequency performance at an economical price. tHE AT-41511 places the same die in the lower parasitic 4 lead SOT-143. The package is industry standard, and compatible with high volume surface mount assembly techniques.

Parametrics

AT-41511 absolute maximum ratings: (1)VEBO, Emitter-Base Voltage: 1.5V; (2)VCBO, Collector-Base Voltage: 20V; (3)VCEO, Collector-Emitter Voltage: 12V; (4)IC, Collector Current: 50mA; (5)PT Power Dissipation: 225mW; (6)Tj, Junction Temperature: 150℃; (7)TSTG, Storage Temperature: -65 to 150℃.

Features

AT-41511 features: (1)General Purpose NPN Bipolar Transistor; (2)900 MHz Performance: 1 dB NF, 15.5 dB GA; (3)Characterized for 3, 5, and 8 Volt Use; (4)SOT-23 and SOT-143 SMT Plastic Packages; (5)Tape-and-Reel Packaging Option Available.

Diagrams

AT-41511 outline drawing

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
AT-41511-BLKG
AT-41511-BLKG

Avago Technologies

Transistors Bipolar (BJT) Transistor Si

Data Sheet

0-2700: $0.11
2700-5000: $0.11
5000-10000: $0.10
AT-41511-TR1G
AT-41511-TR1G

Avago Technologies

Transistors Bipolar (BJT) Transistor Si

Data Sheet

0-1: $0.23
1-25: $0.20
25-100: $0.16
100-250: $0.14
AT-41511-TR2G
AT-41511-TR2G

Avago Technologies

Transistors Bipolar (BJT) Transistor Si

Data Sheet

0-7400: $0.11
7400-10000: $0.10
AT-41511-TR1
AT-41511-TR1


IC TRANS NPN GP BIPOLAR SOT-143

Data Sheet

Negotiable
AT-41511
AT-41511

Other


Data Sheet

Negotiable
