Product Summary

The EMM5717YF is a LNA MMIC designed for applications in the 12.7 - 24.0 GHz frequency range. This product is well suited for satellite communications, radio link and applications where low noise and high dynamic range are required.

Parametrics

EMM5717YF absolute maximum ratings: (1)Drain-Source Voltage: 4 V; (2)Gate-Source Voltage: -3 V; (3)Input Power: 0 dBm; (4)Storage Temperature: -55 to +125 ℃.

Features

EMM5717YF features: (1)Low Noise Figure : NF = 2.0dB ( Typ.) @ f=18 GHz; (2)High Associated Gain : Gas = 23dB ( Typ.) @ f=18 GHz; (3)Broad Band : 12.7 - 24.0 GHz; (4)High Output Power : P1dB = 17.5dBm ( Typ. ); (5)Impedance Matched Zin/Zout = 50ohm.

Diagrams

EMM5717YF block diagram
