Product Summary

The ER3J is a 3.0A surface mount rectifier.

Parametrics

ER3J absolute maximum ratings: (1)Maximum Recurrent Peak Reverse Voltage:600V; (2)Maximum RMS Voltage:420V; (3)Maximum DC Blocking Voltage:600V; (4)Maximum Average Forward Current:3.0A; (5)Peak Forward Surge Current : 8.3ms single half sine-wave superimposed on rated load (JEDEC method):100A; (6)Typical thermal resistance:16℃/W; (7)Maximum Forward Voltage at 3.0A, per element:1.7V; (8)Maximum DC Reverse Current at TJ=25℃:1.0uA; (9)Operating Junction and Storage Temperature Range:-55℃ to +150℃.

Features

ER3J features: (1)For surface mounted applications; (2)High temperature metallurgically bonded-no compression contacts as found in other diode-constructed rectifiers; (3)Glass passivated junction; (4)Built-in strain relief; (5)Easy pick and place; (6)Plastic package has Underwriters Laboratory Flammability Classification 94V-O; (7)In compliance with EU RoHS 2002/95/EC directives.

Diagrams

ER3J package dimensions

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
ER3J
ER3J

Other


Data Sheet

Negotiable
ER3JB
ER3JB

Other


Data Sheet

Negotiable
ER3JB-TP
ER3JB-TP


DIODE SUPER FAST 3A 600V SMB

Data Sheet

0-1: $0.35
1-10: $0.27
10-25: $0.23
25-100: $0.19
100-250: $0.16
250-500: $0.13
500-1000: $0.10
ER3J-TP
ER3J-TP


DIODE SUPER FAST 3A 600V SMC

Data Sheet

0-1: $0.42
1-10: $0.34
10-100: $0.25
100-250: $0.22
250-500: $0.19
500-1000: $0.15
