Product Summary
The FMM5056VF is a MMIC amplifier that contains a four-stage amplifier, internally matched, for standard communications band in the 5.8 to 7.2GHz frequency range.
Parametrics
FMM5056VF absolute maximum ratings: (1)Drain-Source Voltage: 12 V; (2)Gate-Source Voltage: -7 V; (3)Input Power: 12 dBm; (4)Storage Temperature: -55 to +125 ℃.
Features
FMM5056VF features: (1)High Output Power: Pout = 28.0 dBm (Typ.); (2)Low VSWR; (3)Broad Band: 5.8 to 7.2GHz; (4)Impedance Matched Zin/Zout = 50Ω; (5)Hermetically Sealed Package.
Diagrams
 |
