Product Summary
The BLF404 is an UHF power MOS transistor. It is Silicon N-channel enhancement mode vertical D-MOS power transistor in an 8-lead SOT409A SMD package with a ceramic cap. The applications of the BLF404 include Communication transmitters in the VHF/UHF range with a nominal supply voltage of 12.5 V.
Parametrics
BLF404 absolute maximum ratings: (1)drain-source voltage: 40 V; (2)gate-source voltage: ±20 V; (3)DC drain current: 1.5 A; (4)total power dissipation Tmb ≤ 85 ℃: 8.3 W; (5)storage temperature: -65 to 150 ℃; (6)junction temperature: 200 ℃.
Features
BLF404 features: (1)High power gain; (2)Easy power control; (3)Gold metallization; (4)Good thermal stability; (5)Withstands full load mismatch; (6)Designed for broadband operation.
Diagrams
Image | Part No | Mfg | Description | ![]() |
Pricing (USD) |
Quantity | ||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|
![]() |
![]() BLF404 |
![]() Other |
![]() |
![]() Data Sheet |
![]() Negotiable |
|
||||||
![]() |
![]() BLF404,115 |
![]() NXP Semiconductors |
![]() Transistors RF MOSFET Power TRANSISTOR UHF PWR DMOS |
![]() Data Sheet |
![]()
|
|
